Flex Update Unlocks Bosch MDG1 ECUs via Boot Mode

 With Flex 8.1.0.0, Magic Motorsport Flex is expanding its No RFT solution with support for even more Bosch MDG1 ECUs.

More MDG1. More Freedom.

Version 8.1.0.0 of Flex Out Now

With the new Flex update, support to Boot Glitch mode introduced in the previous release expands.

Newly supported:

  • Bosch MD1CS069 TC299 — Fiat Ducato
  • Bosch MD1CS001 TC298 — BMW
  • Bosch MD1CP006 TC298 — Ford

Unlock them directly in your workshop using Boot Glitch Mode. No shipping. No Remote Force Team. Just a faster workflow and complete autonomy.
This is another step toward making the entire Bosch MDG1 TC2xx family available directly with Flex.

Thanks to the new update, you can manage more Bosch MDG1 with Aurix TC2xx microprocessor, directly in your workshop, no shipping, no RFT service.

This new support is available to all the customers with Flex Full Master (FLS0.5M) and Flex Full Slave (FLS0.5S) licenses.

Key Insights:

  • Working Mode: Boot Glitch — Bench
  • Memories: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Backup, Boot Unlock
  • License: FLS0.5M/S
  • Connect/Glitch Time : From 10 seconds to 25 minutes (variable)
  • Reading Time : ~ 2 minutes and 30 seconds
  • Writing Time : ~ 2 minutes

Some of the supported models:

  • Ford F-250 Super Duty (V) 6.7L V8 Power Stroke 474HP (2023MY)
  • Ford F-350 Super Duty (V) 6.7L V8 Power Stroke HO 500HP (2023MY)
  • Fiat Ducato (V) 2.2L MultiJet III 118HP (2021MY)
  • Fiat Ducato (V) 2.2L MultiJet III 138HP (2021MY)
  • BMW 2-Series (II) 2.0L 220d MHEV 188HP (2021MY)
  • BMW 4-Series 2.0L 420d MHEV 188HP (2020MY)

MMS Flex Update MD1CS069 MD1CS001 MD1CP006 Boot Unlocking
