Can PCMTuner Read EDC7C32 MPC?

 Question: Can we read edc7c32 mpc module 77 with pcmtuner ? Anybody tried it yet? Answer: For edc7c32 you must pcmflash OEM with module 77. there is no module 77, and module 71 will only work with edc17 engine control units.

PCMTuner Read and Write Citroen Jumper 2014 SID208

 Citroen Jumper 2014, 96kW, 2.2HDi SID208 S180129101J Continental pcmtuner read password by OBD on the table, Read/Write BENCH (I opened the ECU and connect two 1K resistors as in the PCM manual) DPF, DTC OFF 100% You can use godiag obd breakout cable for password via obd on bench Follow the tutorial: PCMTuner SID208 SID209 BSL Instruction

PCMTuner User Manual: Modules 35, 46 for Toyota

 Here’s the PCMTUNER INFORMATION FOR MODULE 35 and 46. Module 35 Toyota/Lexus/Scion/Hino generation 1 The package consists of three modules, which differ in the type of connection with the blocks. 6F0038/39/40/70/85, MPC565, SH72512 CAN-bus — for operation via CAN bus 76F0004/23/38/39/40, MPC565 K-Line — for K-Line operation 76F0004/23/38/39/40 K-Line JDM — for K-Line operation for the Japanese market. The type of processor is indicated for general information, the program will automatically determine everything that it needs. Checksum verification and correction is supported. These processors are installed in units manufactured by Denso, Fujitsu Ten, Hitachi/Delphi. Important: Before working on the vehicle, read the general rules that must be observed. Start working with the control unit with identification until it happens with a positive result. After that, find a file with a completely matching software version and start recording. On machines with K-Line, ...
