FormulaFlash New version: Free ECU Data Cloud Processing

 Formulaflash ECU data cloud processing platform is officially launched and Beta version is available (DTC/DPF/GPF/OPF/EGR/EVAP/AdBlue are free and available to all users in the beta version. By ticket system, engineers will manually process the data for you for free).

All data processing is handled manually by engineers through a convenient ticket system, ensuring accurate and reliable results every time.

[VERSION] V1.0.4.0
[UPDATED] JUNE 13, 2025

NEW PROTOCOLS

  • DELPHI DCM7.1AP SERIES EEPROM DATA READ AND WRITE
  • PORSCHE SD16, SD17, SD18 BENCH READ AND WRITE
  • CKS+ IDLE SPEED ADJUSTMENT
  • BAIC 1.5L R15C1 (AECS FC-34)
  • CHANGAN 1.2L LJ469Q (AECS FC-34)
  • CHANGAN 1.5L DAM15KL (AECS FC-34)
  • DONGFENG 1.5L LA415Q (AECS FC-34)
  • DONGFENG/FENGXING 1.5T 4J15T (AECS FC-34)
  • DONGFENG/FENGXING 1.6L A492FR (AECS FC-34)
  • JAC 1.6L DAM16KL/HFC4GB3 (AECS FC-34)
  • JAC 1.8L, 2.0L, 2.0T LJ4A1806/LJ481Q/HFC4NA3 (AECS FC-34/FC-51)
  • JINBEI/SWM/BRILLIANCE 1.5L SWC15M (AECS FC-34)
  • JINLU/JINLONG 2.0L LJ481 (AECS FC-34)
  • KING LONG/JINLONG 1.8L LJ4A18 (AECS FC-34)
  • LDV/SAIC 1.5L LJ4A15 (AECS FC-34)
  • SGMW 1.8L, 2.0L LJ479Q6/LJM208 (AECS FC-34/FC-50)
  • SHANDONG KAMA 1.6L DAM16KR (AECS FC-34)
  • XIAMEN GOLDEN DRAGON 1.8L LJ4A18 (AECS FC-34)
  • GEELY 01609492 1 (EASY U2)
  • SGMW 1.2L N12 (EASY U2.5)
  • SGMW 1.5L B15 (EASY U2W)
  • SGMW 1.5L N15A (EASY U3.6)
  • SGMW 1.5L N15T (EASY U3D/USE)


FormulaFlash Adds ECU Data Cloud Processing

FORMULAFLASH ECU DATA CLOUD PROCESSING PLATFORM

BETA VERSION LAUNCHED

Depending on the improvement of the ticket system, users will get free ECU data processing services in the beta system version.

DTC OFF new update
(The database is updated daily)

— VW Audi Porsche Seat Skoda BOSCH:
MED (MED17.1_17.5_17.6_17.1.X_17.1.XX_17.5.XX Series, including: MED17.5.20, MED17.5.22, MED17.1, MED17.1.1, MED17.1.6, MED17.1.10, MED17.1.27, MED17.1.61, MED17.5.2, MED17.5.5, MED17.5)

— Hyundai/Kia Bosch:
ME, MED(C) 17.9.8, 17.9.2, 17.9.21, 17.9.(11 12 13) (TC1724, TC1764, TC1762, TC1767) 2MB, 1.5MB

— Volkswagen/Audi/Porsche:
SIMOS 8.1, SIMOS 8.2, SIMOS 8.3, SIMOS 8.4, SIMOS 8.5, SIMOS 8.6, SIMOS 10, SIMOS 11, SIMOS 12, PCR2.1, SIMOS18.x, SI-MOS16.x, SIMOS19.x, Temic AL551, Temic AL552, Temic DQ200, Temic DQ250, Temic DQ380/DQ381, Temic DQ400, Temic DQ500

— Mercedes-benz:
SIM271DE/SIM271DE2.0, SIM271KE/SIM271KE2.0

— Porsche:
SDI6, SDI7, SDIB, SDI9 VAG Bosch ME(D)17.5/17.5.2/17.5.2/17.5.2/17.5.2/17.5.25/17.5.5/17.5.6

— Delphi:
DCM7.1AP

— Delphi China:
MT62, MT62.1, MT62.3 SPC5634 1.5MB, MT80 TC1762, MT92/MT92.1/MT92.1E TC265 2.5MB, MT95.1, MT20U/MT20U2/MT20U2/MT20U2 256KB (METAL CASING), 德尔福 MT22.3, MT22.5 SPC563M64 1.5MB, MT22.1 512KB, MT22.1 768KB, MT22.1.1 256KB, MT20U 1
EDC17C55, EDC17C81, EDC17C63, EDC17C53, EDC17C83 TC1793 4M

— Bosch China:
ME17.8.8 TC1728, MED17.8.10 TC1728, MED17.8.2 TC1767, MG1US008 UD8 TC277 4MB, MG1US708 080 TC387 10MB, MG1UA008 UP8 SPC574 2.5MB
BMW MSV90, MSV80, MSV70, MSD80/81/85/87

— Delco:
E83, E39, E80

— Delphi China:
DCM6.2, DCM6.2AP, DCM3.2, DCM3.2AP, DCM3.7, DCM3.7AP

— China AECS:
FC-50 (BETA), FC-51 (BETA)

— Lindian:
LEC4AP 1.5MB, LEC4AF

— Geely:
01609492 (Easy U2)

— Wuling:
SIM2K-D51, SIM2K-51.4, SCE60, SGMW 1.2L N12 (Easy U2.5), SGMW 1.5L B15 (Easy U2W), SGMW 1.5L N15A (Easy U3.6), SGMW 1.5L N15T EASy U3D/U3E

— Bosch CHINA:
MD1CS089 8MB, MD1CC878 6MB, MD1CE108 6MB


FormulaFlash Adds ECU Data Cloud Processing
