How to Read and Write Ford Ranger 2018 SID209 using Foxflash

 It is a Ford Ranger 2.2 year 2018 with SID209 ECU.

Foxflash read ID via OBD, read data via OBD, write via OBD all ok.
A lot people say you can’t write back via obd on the SID209.
Here used the Ford Custom with the sid209 full read via OBD. Need power supply 14V.

Patience is the key. It did fail to write about 5–6 times (because of wifi connection)
But it does work.
Dpf and adblue solution.


Foxflash Read and Write Ford Ranger 2018 SID209 via OBD
Foxflash Read and Write Ford Ranger 2018 SID209 via OBD
Foxflash Read and Write Ford Ranger 2018 SID209 via OBD

www.iecutool.eu
